Datalogic DSM0400 User Manual

Technical Features
Product Reference Guide 225
DSM04X1 models (WVGA)
Resolution: 752x480
Field of View: 40°H x 26°V
Typical Depth of Field
Symbology
a
a. All labels grade A, ambient light level 300lux, pitch angle 10°, tilt angle 10°, skew angle 0°,
room temperature 20°C.
Resolution (mils) Dmin (mm) Dmax (mm)
Code 39 3 80 175
Code 39 5 55 260
PDF 10
(-)
b
b. Limited by field of view.
200
EAN13 13 45 420
Datamatrix 15 35 265
Code 39 20
(-)
b
590
DSM04X2-DL models (MP)
Resolution: 1280x960
Field of View: 42°H x 32°V
Typical Depth of Field
Symbology
a
a. All labels grade A, ambient light level 300lux, pitch angle 10°, tilt angle 10°, skew angle 0°,
room temperature 20°C.
Resolution (mils) Dmin (mm) Dmax (mm)
Code 39 3 65 200
Code 39 5 35 290
Datamatrix 10 75 260
EAN13 13 45 420
Datamatrix 15 55 320
Code 39 20
(-)
b
b. Limited by field of view
600
DSM04X2-SR models (MP)
Resolution: 1280x960
Field of View: 42°H x 32°V
Typical Depth of Field
Symbology
a
a. All labels grade A, ambient light level 300lux, pitch angle 10°, tilt angle 10°, skew angle 0°,
room temperature 20°C.
Resolution (mils) Dmin (mm) Dmax (mm)
Code 39 3 130 220
Code 39 5 85 360
Datamatrix 10 100 280
EAN13 13 45 740
Datamatrix 15 65 400
Code 39 20
(-)
b
b. Limited by field of view
1100
