Performance Characteristics
Nominal Frame Rate
53 frames/second (Mpixel models)
or
60 frames/second
(WVGA models)
Light Source Dual LEDs
Roll (Tilt) Tolerance Up to ± 180°
Pitch Tolerance ± 60°
Skew (Yaw) Tolerance ± 60°
Print Contrast Minimum 25% minimum reflectance
Field of View Depending on the selected model, see the tables below
Depth of Field (Typical) Depending on the selected model, see the tables below
Minimum Element Width
1D linear: 2 mils (MP-DL) - 3 mils (MP-SR)
Data Matrix: 6 mils (MP-DL) - 7.5 mils (MP-SR)
PDF417: 3 mils (MP-DL) - 6.6 mils (MP-SR)
1D Linear: 3mils (WVGA)
PDF: 5mils (WVGA)
Datamatrix: 7.5mils (WVGA)
NOTE
Decode Capability
1D / Linear Codes
All standard 1D codes including: UPC/EAN/JAN, P2 /P5 add-ons; Code 39; Italian Pharma
code 39;
Code 128; C128 ISBT; I 2 of 5; Standard 2 of 5; Interleaved 2 of 5; Industrial 2of 5; Datalogic 2of5;
IATA; Code 11; Codabar; ABC Codabar; EAN 128; Code 93; MSI/Plessey; RSS-14; BC412; Databar
Limited; Databar Omnidirectional; Databar Omnidirectional Stacked; Databar Expanded; Databar
Expanded Stacked; IATA; Trioptic; Matrix 2/5; Telepen.
Composite codes CC-A, CC-B and CC-C
PDF417; MicroPDF417.
2D Codes
China Han Xin Code; Datamatrix with Chinese exten
sion; QR code; Micro QR; Aztec; MaxiCode and
Dotcode.
Postal Codes
Australian Post; British Post; China Post; Portugal
Post; Swedish Post; New Zeland Post; Japanese
Post; KIX Post; IMB; Planet Code; Postnet, Postnet BB; Royal Mail Code (RM4SCC) ; Mailmark.
Supported Interfaces
RS-232 Standard
USB-COM, USB-Keyboard, USB-OE
M, USB-Composite
RJ45 with Datalogic USB and RS232 cables:
90A052065: USB 2m straight cable
90A051230: RS232 2m straight cable
User Environment
Operating Temperature -20° to 50° C
Storage Temperature
-40° to 70° C
a
a. Storage conditions for EAC Compliance require the device to be kept in a heated room.
Humidity Operating: 5% to 90% relative humidity, non condensing
Drop specifications 3ft free fall drops to concrete
Ambient Light immunity Up to 100,000 Lux
Contaminants IEC529-IP54
ESD Level 12 KV
Regulatory See the Regulatory Addendum.
The reading performances may change with different symbologies
Technical Specifications
224 DSM0400 Fixed Mount Area Imager Bar Code Reader
