Enter/Exit Programming Mode
Product Reference Guide 123
Industrial 2 of 5 Set Length 2
This feature specifies one of the barcode lengths for Industrial 2 of 5. Length 2
is the maximum label length if in
Variable Length on page 93
Mode, or the second
fixed length if in
Fixed Length on page 93
Mode. Length includes the barcode’s
check, data, and full-ASCII shift characte
rs. The length does not include start/
stop characters.
The length can be set from 1 to 50 characte
rs. A setting of 0 specifies to ignore
this length (only one fixed length). For more detailed programming instructions
see, "Set Length" on
Chapter 4, References
.
Table 10
provides examples for setting Length 2.
Table 10. Industrial 2 of 5 Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (Ignore This
Length)
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT INDUSTRIAL 2 OF 5 LENGTH 2 SETTING
4
Scan Two Characters From
Appendix C
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select Industrial 2 of5 Length 2 Setting
Make a mistake? Scan the CANCEL barcode to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
50 = Length 2 is 50 Characters
To Next Page
