Enter/Exit Programming Mode
Product Reference Guide 19
Data Bits
This parameter allows the reader to interface with devices requiring a 7-bit or
8-bit ASCII protocol for sending and receiving data.
7 Data Bits
8 Data Bits
Stop Bits
The stop bit(s) at the end of each transmitted character marks the end of trans-
mission of one character and prepares the receiving device for the next charac-
ter in the serial data stream. The number of stop bits selected (one or two)
de
pends on the number the receiving terminal is programmed to accommo-
date. Set the number of stop bits to
match host device requirements.
1 Stop Bit
2 Stop Bits
