Enter/Exit Programming Mode
Product Reference Guide 161
Plessey Set Length 2
This feature specifies one of the barcode lengths for
Plessey Length Control on
page 159
. Length 2 is the maximum label length if in
Variable Length on page 93
Mode, or the second fixed length if in
Fixed Length on page 93
Mode. Length
includes the barcode’s check, data, and full-ASCII shift characters. The length
doe
s not include start/stop characters. For more detailed programming
instructions see, "Set Length" on
Chapter 4, References
.
The length can be set from 1 to 50 characters. A setting of 0 specifies to ignore
this length (only one fixed length).
Table 24
provides examples for setting Length 2.
Table 24. Plessey Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (Ignore This
Length)
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT PLESSEY LENGTH 2 SETTING
4
Scan Two Characters From
Appendix C
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select Plessey Length 2 Setting
Make a mistake? Scan the CANCEL barcode to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
DEFAULT
50 = Length 2 is 50 Characters
