134 DSM0400 Fixed Mount Area Imager Bar Code Reader
Codabar Set Length 2
This feature specifies one of the barcode lengths for Codabar. Length 2 is the
maximum label length if in
Variable Length on page 93 Mode, or the second fixed
length if in
Fixed Length on page 93 Mode. The length includes the barcode’s
start, stop, check and data characters. The length must include at least one
da
ta character.
The length can be set from 3 to 50 characte
rs. A setting of 0 specifies to ignore
this length (only one fixed length). For more detailed programming instructions
see, "Set Length" on
Chapter 4, References .
Table 14 provides examples for setting Length 2.
Table 14. Codabar Length 2 Setting Examples
STEP ACTION EXAMPLES
1
Desired Setting (and pad
with leading zeroes)
00 Ignore This
Length
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODABAR LENGTH 2 SETTING
4
Scan Two Characters From
Appendix C
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select Codabar Length 2 Setting
Make a mistake? Scan the CANCEL barcode to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
DEFAULT
50 = Length 2 is 50 Characters
