GS1 DataBar™ Expanded Set Length 1

This feature specifies one of the barcode lengths for GS1 DataBar™ Expanded.

Length 1 is the minimum label length if in

Variable Length on page 93

Mode, or

the first fixed length if in

Fixed Length on page 93

Mode. Length includes the bar-

code’s data characters only.

The length can be set from 1 to 74 characters. For

more detailed programming instructions see, "Set Length" on

Chapter 4, Refer-

ences

Table 17

provides some examples for setting Length 1.

Table 17. GS1 DataBar™ Expanded Length 1 Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

01 Character 07 Characters 52 Characters 74 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT GS1 DataBar™ EXPANDED LENGTH 1SETTING

Scan Two Characters From

Appendix C

‘0’ and ‘1’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ AND ‘4’

5 Scan ENTER/EXIT PROGRAMMING MODE

Select GS1 DataBar™ Expanded Set Length 1 Setting

Make a mistake? Scan the CANCEL barcode to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

01 = Length 1 is 1 Character
