Enter/Exit Programming Mode
Product Reference Guide
67
Pick Mode
Specifies the abil
ity of the re
ader to decode labe
ls only when they
are close to
the center o
f the aiming pattern
. This allows the
reader to accurately targ
et
labels when they are placed close
together, such as on a pick sheet.
The Pick Mode can be
en
abled only in Trigger Single Sc
an Mode.
NOTE
This fea
ture is no
t compa
tible w
ith Mu
ltiple Lab
els Read
ing in a Vo
lume.
DEF
A
UL
T
Pick Mode = Disable
Pick Mode = Enable
74
76
