Delta VFD-E Series User Manual

E-15
Delta Definition Part:
Index Sub Definition
Factory
Setting
R/W Size Unit NOTE
2020
0 Number 3 RO U8
1 Control word 0 RW U16
bit 0 ~ 1
00B：No function
01B：Stop
10B：Start
11B：JOG Start
Bit2~3 Reserved
Bit4~5
00B：No function
01B：Forward
Command
10B：Reverse
Command
11B： Direction Change
Command
Bit6~7
00B：1st step accel /
decal
01B：2nd step accel /
decel
Bit8~15 Reserved
2 vl target velocity 0 RW U16 Hz
3 Other trigger 0 RW U16
Bit0
1：E.F. ON
Bit1
1：Reset Command
Bit2~15 Reserved
0x2021
0 Number 0xD RO U8
1 Fault code 0 RO U16
2 Drive Status 0 RO U16 Bit 0~1
00B：Drive stop
01B：Drive decelerates
stopping
