Delta VFD-E Series User Manual

E-16
10B：Drive operation
waits for frequency
command
11B：Drive operates
Bit 2
1：JOG Command
Bit 3~4
00B：Drive Forward
01B：Drive from reverse
to forward
10B：Drive from forward
to reverse
11B：Drive Reverse
Bit 5~7 Reserved
Bit 8
1：Main frequency
source from the
communication interface
Bit 9
1：Main frequency
source from the analog
signal input
Bit 10
1：Operation command
from the communication
interface
Bit
11~15
Reserved
3
Frequency
Command（F）
0 RO U16 Hz
4
Output
Frequency（H）
0 RO U16
5
Input Current
（AXX.X）
0 RO U16
6
Reserved
0 RO U16
7
Reserved
0 RO U16
8
Reserved
0 RO U16
9
DC-BUS Voltage
（uXXX.X）
0 RO U16
