Chapter 14: Solo and Monitor Busses 119
Activating 2-Track Input and Setting Level
To activate and set the general level for 2-Track Input:
1 Press the 2-Track switch in the Talkback/Osc section so that
it is lit.
2 Activate 2-Track input by doing one of the following:
• Press the On/Talk switch in the Talkback/Osc section.
– or –
• Click the on-screen “In” button in the 2-Track section of
the Options > Misc page.
3 Set the 2-Track input level by doing one of the following:
• Turn the Level knob in the Talkback/Osc section.
– or –
• Drag the on-screen Level knob in the 2-Track section of
the Options > Misc page.
Routing 2-Track Output
You can route any output bus or Direct Output to the 2-Track
output on the FOH rack.
To route any D-Show Output bus to the 2-Track outputs:
1 Go to the Patchbay and click the Outputs tab.
2 To the left of the channel grid, click the tab for an Output
bus (Auxes, Groups, PQs, Matrixes, or Mains).
3 At the top of the channel grid, click the FOH tab.
4 Click in the channel grid to assign an Output bus (listed on
the left) to any of the following 2-Track output sources (listed
at the top right of the grid):
• AL (Analog Left)
• AR (Analog Right)
• DL (Digital Left)
• DR (Digital Right)
To route any D-Show Direct Output to the 2-Track outputs:
1 Go to the Patchbay and click the Directs tab.
2 To the left of the channel grid, click the tab for a channel
source (Channels, FX Returns, or Outputs).
3 At the top of the channel grid, click the FOH tab.
4 Click in the channel grid to assign a channel source (listed
on the left) to any of the following 2-Track output sources
(listed at the top right of the grid):
• AL (Analog Left)
• AR (Analog Right)
• DL (Digital Left)
• DR (Digital Right)
Previewing 2-Track Output on the Monitor Bus
You can route the 2-Track output signal directly to the Moni-
tor bus. You do not have to have the “On/Talk” switch on for
this routing to be active.
To preview 2-Track output on the Monitor bus:
■ In the Talkback/Osc section, press the Level encoder. The
encoder’s indicator LED lights when 2-Track routing is acti-
vated.
2-Track controls in the Options > Misc page
Signals are routed to output busses post-mute and post
fader.
Routing 2-Track output in the Patchbay
