Configuring the Switch
3-78
3
www.digisol.com
CLI – This example sets the 802.1X parameters on port 2. For a description of the
additional fields displayed in this example, see “show dot1x” on page 4-105.
Console(config)#interface ethernet 1/2 4-150
Console(config-if)#dot1x port-control auto 4-101
Console(config-if)#dot1x re-authentication 4-102
Console(config-if)#dot1x max-req 5 4-100
Console(config-if)#dot1x timeout quiet-period 30 4-103
Console(config-if)#dot1x timeout re-authperiod 1800 4-104
Console(config-if)#dot1x timeout tx-period 40 4-104
Console(config-if)#dot1x intrusion-action guest-vlan 4-105
Console(config-if)#exit
Console(config)#exit
Console#show dot1x 4-105
Global 802.1X Parameters
system-auth-control: enable
802.1X Port Summary
Port Name Status Operation Mode Mode Authorized
1/1 disabled Single-Host ForceAuthorized n/a
1/2 enabled Single-Host auto yes
.
.
.
1/10 disabled Single-Host ForceAuthorized n/a
802.1X Port Details
802.1X is disabled on port 1/1
802.1X is enabled on port 1/2
reauth-enabled: Enable
reauth-period: 1800
quiet-period: 30
tx-period: 40
supplicant-timeout: 30
server-timeout: 10
reauth-max: 2
max-req: 5
Status Authorized
Operation mode Single-Host
Max count 5
Port-control Auto
Supplicant 00-24-8C-0f-fa-dc
Current Identifier 3
Intrusion action Guest VLAN
Authenticator State Machine
State Authenticated
Reauth Count 0
Backend State Machine
State Idle
Request Count 0
Identifier(Server) 2
Reauthentication State Machine
State Initialize
.
.
.
802.1X is disabled on port 1/10
Console#
