Configuring the Switch
3-172
3
www.digisol.com
critical to the timely startup of LLDP, and therefore integral to the rapid availability
of Emergency Call Service.
Web – Click LLDP, Configuration. Enable LLDP, modify any of the timing parameters
as required, and click Apply.
Figure 3-105 LLDP Configuration
CLI – This example sets several attributes which control basic LLDP message
timing.
Configuring LLDP Interface Attributes
Use the LLDP Port/Trunk Configuration to specify the message attributes for
individual interfaces, including whether messages are transmitted, received, or both
transmitted and received, whether SNMP notifications are sent, and the type of
information advertised.
Console(config)#lldp 4-180
Console(config)#lldp refresh-interval 60 4-182
Console(config)#lldp holdtime-multiplier 10 4-180
Console(config)#lldp tx-delay 10 4-183
Console(config)#lldp reinit-delay 10 4-183
Console(config)#lldp notification-interval 30 4-181
Console(config)#lldp medFastStartCount 6 4-181
Console(config)#exit
Console#show lldp config
LLDP Global Configuation
LLDP Enable : Yes
LLDP Transmit interval : 60
LLDP Hold Time Multiplier : 10
LLDP Delay Interval : 10
LLDP Reinit Delay : 10
LLDP Notification Interval : 30
.
.
.
