DG-FS4526 User Manual
3-191
3
www.digisol.com
Web* – Click Priority, IP Precedence Priority. Select an IP Precedence value in the
IP Precedence Priority Table, enter a queue number in the Class of Queue Service
Value field, and then click Apply.
Figure 3-121 Mapping IP Precedence to Class of Service Queues
CLI* – The following example globally enables IP Precedence priority on the switch,
maps IP Precedence value 2 to CoS queue 0, and then displays all the IP
Precedence settings.
* Mapping specific values for IP Precedence priority applies to all interfaces on the switch.
Console(config)#map ip precedence 4-255
Console(config)#map ip precedence 1 cos 0 4-255
Console(config)#end
Console#show map ip precedence 4-259
Precedence Mapping Status: Enabled
Precedence COS
---------- ---
0 0
1 0
2 0
3 1
4 2
5 2
6 3
7 3
Console#
