Configuring the Switch
3-112
3
www.digisol.com
CLI – The following example displays the LACP configuration settings and
operational state for the local side of port channel 1.
Displaying LACP Settings and Status for the Remote Side
You can display configuration settings and the operational state for the remote side
of an link aggregation.
Console#show lacp 1 internal 4-171
Port channel : 1
-------------------------------------------------------------------------
Oper Key : 120
Admin Key : 0
Eth 1/1
-------------------------------------------------------------------------
LACPDUs Internal: 30 sec
LACP System Priority: 3
LACP Port Priority: 128
Admin Key: 120
Oper Key: 120
Admin State : defaulted, aggregation, long timeout, LACP-activity
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
Table 3-10 LACP Neighbor Configuration Information
Field Description
Partner Admin System ID LAG partner’s system ID assigned by the user.
Partner Oper System ID LAG partner’s system ID assigned by the LACP protocol.
Partner Admin Port Number Current administrative value of the port number for the protocol Partner.
Partner Oper Port Number Operational port number assigned to this aggregation port by the port’s
protocol partner.
Port Admin Priority Current administrative value of the port priority for the protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding table.)
Oper State Operational values of the partner’s state parameters. (See preceding table.)
