Configuring the Switch
3-182
3
www.digisol.com
CLI – This example assigns a default priority of 5 to port 3.
Mapping CoS Values to Egress Queues
This switch processes Class of Service (CoS) priority tagged traffic by using four
priority queues for each port, with service schedules based on Strict, Weighted
Round Robin (WRR), or Hybrid. Up to eight separate traffic priorities are defined in
IEEE 802.1p. The default priority levels are assigned according to recommendations
in the IEEE 802.1p standard as shown in the following table.
The priority levels recommended in the IEEE 802.1p standard for various network
applications are shown in the following table. However, you can map the priority
levels to the switch’s output queues in any way that benefits application traffic for
your own network.
Console(config)#interface ethernet 1/3 4-150
Console(config-if)#switchport priority default 5 4-248
Console(config-if)#end
Console#show interfaces switchport ethernet 1/3 4-159
Information of Eth 1/3
Broadcast Threshold: Enabled, scale:1000K level:5 octets/second
LACP Status: Disabled
Ingress Rate Limit: Disabled, scale:10M level:1
Egress Rate Limit: Disabled, scale:10M level:1
VLAN Membership Mode: Hybrid
Ingress Rule: Enabled
Acceptable Frame Type: All frames
Native VLAN: 1
Priority for Untagged Traffic: 5
GVRP Status: Disabled
Allowed VLAN: 1(u),4093(t),
Forbidden VLAN:
Private-VLAN Mode: NONE
Private-VLAN host-association: NONE
Private-VLAN Mapping: NONE
802.1Q-tunnel Status: Disable
802.1Q-tunnel Mode: NORMAL
802.1Q-tunnel TPID: 8100(Hex)
Console#
Table 3-12 Mapping CoS Values to Egress Queues
Queue
0123
Priority
1,20,34,56,7
Table 3-13 CoS Priority Levels
Priority Level Traffic Type
1 Background
2(Spare)
0 (default) Best Effort
3 Excellent Effort
4 Controlled Load
5 Video, less than 100 milliseconds latency and jitter
