Configuring the Switch
3-180
3
www.digisol.com
Displaying Detailed Device Statistics
Use the LLDP Device Statistics Details screen to display statistics based on traffic
received through all attached LLDP-enabled interfaces.
Web – Click LLDP, Device Statistics Details.
Figure 3-111 LLDP Device Statistics Details
CLI – This example displays detailed LLDP statistics for an LLDP-enabled remote
device attached to a specific port on this switch.
Class of Service Configuration
Class of Service (CoS) allows you to specify which data packets have greater
precedence when traffic is buffered in the switch due to congestion. This switch
supports CoS with four priority queues for each port. Data packets in a port’s
high-priority queue will be transmitted before those in the lower-priority queues. You
switch#show lldp info statistics detail ethernet 1/1 4-199
LLDP Port Statistics Detail
PortName : Eth 1/1
Frames Discarded : 0
Frames Invalid : 0
Frames Received : 12
Frames Sent : 13
TLVs Unrecognized : 0
TLVs Discarded : 0
Neighbor Ageouts : 0
switch#
