- If the frame is untagged and the protocol type matches, the frame is
forwarded to the appropriate VLAN.
- If the frame is untagged but the protocol type does not match, the frame is
forwarded to the default VLAN for this interface.
Example
The following example maps the traffic entering Port 1 which matches the protocol
type specified in protocol group 1 to VLAN 2.
show protocol-vlan protocol-group
This command shows the frame and protocol type associated with protocol groups.
Syntax
show protocol-vlan protocol-group [group-id]
group-id - Group identifier for a protocol group. (Range: 1-2147483647)
Default Setting
All protocol groups are displayed.
Command Mode
Privileged Exec
Example
This example shows many protocol groups configured for various protocol-types and
frame-types:
Console(config)#interface ethernet 1/1
Console(config-if)#protocol-vlan protocol-group 1 vlan 2
Console(config-if)#
Console#sh protocol-vlan protocol-group
ProtocolGroup ID Frame Type Protocol Type
------------------ ------------- ---------------
4 Ethernet 0B AD
8 Ethernet 80 2E
5000 Ethernet 81 37
12 Ethernet 81 46
5000 Ethernet 86 DD
6 RFC 1042 43 21
10 RFC 1042 80 49
7 SNAP 802.1h 80 3C
11 SNAP 802.1h 80 A3
50 SNAP 802.1h 81 2B
5000 SNAP 802.1h 86 DD
1 08 00
3 80 9B
2 81 37
