Configuring the Switch
3-232
3
www.digisol.com
Web – Click IP Source Guard, Port Configuration.
Figure 3-149 IP Source Guard Port Configuration
CLI – This example shows how to enable IP source guard on port 5
.
Static IP Source Guard Binding Configuration
Adds a static addresses to the source-guard binding table. Table entries include a
MAC address, IP address, lease time, entry type (Static, Dynamic), VLAN identifier,
and port identifier. All static entries are configured with an infinite lease time, which
is indicated with a value of zero in the table.
Command Attributes
• Static Binding Table Counts – The total number of static entries in the table.
• Port – Switch port number. (Range: 1-26)
• VLAN ID – ID of a configured VLAN (Range: 1-4094)
• MAC Address – A valid unicast MAC address.
• IP Address – A valid unicast IP address, including classful types A, B or C.
Console(config)#interface ethernet 1/5
Console(config-if)#ip source-guard sip 4-310
Console(config-if)#end
Console#show ip source-guard 4-313
Interface Filter-type
--------- -----------
Eth 1/1 DISABLED
Eth 1/2 DISABLED
Eth 1/3 DISABLED
Eth 1/4 DISABLED
Eth 1/5 SIP
Eth 1/6 DISABLED
.
.
