Configuring the Switch
3-206
3
www.digisol.com
Web – Click QoS, VoIP Traffic Setting, OUI Configuration. Enter a MAC address that
specifies the OUI for VoIP devices in the network. Select a mask from the pull-down
list to define a MAC address range. Enter a description for the devices, then click
Add.
Figure 3-130 Telephony OUI List
CLI – This example adds an identifier to the list, then displays the current list
Console(config)#voice vlan mac-address 00-e0-bb-00-00-00 mask
ff-ff-ff-00-00-00 description old phones 4-271
Console(config)#exit
Console#show voice vlan oui 4-275
OUIAddress Mask Description
00-e0-bb-00-00-00 FF-FF-FF-00-00-00 old phones
00-11-22-33-44-55 FF-FF-FF-00-00-00 new phones
00-98-76-54-32-10 FF-FF-FF-FF-FF-FF Chris' phone
Console#
