Queue Scheduling Configures Weighted Round Robin queueing 3-184
IP DSCP Priority Status Globally enables DSCP priority 3-186
IP DSCP Priority Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service queue
3-187
IP Port Priority Status Globally enables IP port priority 3-188
IP Port Priority Sets IP port priority, mapping TCP/UDP ports to class-of-service
queues
3-188
IP Precedence Priority Status Globally enables IP precedence priority 3-190
IP Precedence Priority Sets IP precedence priority, mapping IP precedence values to
class-of-service queues
3-190
IP TOS Priority Status Globally enables IP ToS priority 3-192
IP TOS Priority Sets IP ToS priority, mapping IP ToS values to class-of-service
queues
3-192
ACL CoS Priority Sets ACL priority, mapping IP and MAC ACLs to class-of-service
queues
3-194
QoS 3-195
DiffServ 3-195
Class Map Sets Class Maps 3-196
Policy Map Sets Policy Maps 3-198
Service Policy Defines service policy settings for ports 3-201
VoIP 3-202
Configuration Sets a Voice VLAN ID and enables VoIP traffic detection 3-202
Port Configuration Configures port VoIP traffic mode, security, and priority 3-203
OUI Configuration Configures VoIP device OUI identification 3-205
IGMP Snooping 3-207
IGMP Configuration Enables multicast filtering; configures parameters for multicast
query
3-208
IGMP Filter Configuration Configures IGMP filtering 3-216
IGMP Immediate Leave Enables the immediate leave function 3-210
Multicast Router
Port Information
Displays the ports that are attached to a neighboring multicast
router for each VLAN ID
3-211
Static Multicast Router Port
Configuration
Assigns ports that are attached to a neighboring multicast router 3-212
IP Multicast Registration
Table
Displays all multicast groups active on this switch, including
multicast IP addresses and VLAN ID
3-213
IGMP Member Port Table Indicates multicast addresses associated with the selected
VLAN
3-214
Table 3-2 Main Menu (Continued)
Menu Description Page
