LEFT REAR FOG LAMP (BUILT-UP-EXPORT) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 Z1 16BK GROUND
2- -
3 L38 16BR/WT REAR FOG LAMP FEED
LEFT REAR SPEAKER - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X57 18BR/LB LEFT REAR SPEAKER (-)
2 X51 18BR/YL LEFT REAR SPEAKER (+)
LEFT REAR TURN SIGNAL LAMP (BUILT-UP-EXPORT) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2- -
3 L63 18DG/RD LEFT TURN SIGNAL
LEFT REAR WHEEL SPEED SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B4 20LG 12 VOLT SUPPLY
2 B3 20LG/DB LEFT REAR WHEEL SPEED SENSOR SIGNAL
LEFT SEAT AIRBAG-2WAY
CAV CIRCUIT FUNCTION
1 R31 18OR LEFT SEAT SQUIB LINE 2
2 R33 18WT LEFT SEAT SQUIB LINE 1
PL 8W-80 CONNECTOR PINOUTS 8Wa - 80 - 39
ProCarManuals.com
2001 NEON
