POWERTRAIN CONTROL MODULE (1.6L) - 90 WAY
CAV CIRCUIT FUNCTION
36 - -
37 - -
38 K107 18YL LEAK DETECTION PUMP SWITCH SENSE
39 K10 20WT STEERING PRESSURE SWITCH SENSE
40 G9 20GY/BK RED BRAKE WARNING INDICATOR DRIVER
41 D20 20LG SCI RECEIVE
42 K944 20BR/GY CAMSHAFT POSITION SENSOR GROUND
43 F854 20GY/PK CAMSHAFT POSITION SENSOR 8V SUPPLY
44 K7 20OR 5V SUPPLY
45 F857 20OR/PK VEHICLE SPEED SENSOR 8V SUPPLY
46 K22 20BR/OR THROTTLE POSITION SENSOR NO. 1 SIGNAL
47 K141 20TN/WT OXYGEN SENSOR 1/2 SIGNAL
48 - -
49 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
50 G6 20GY ENGINE OIL PRESSURE SWITCH SENSE
51 - -
52 - -
53 K127 20DB/OR OXYGEN SENSOR GROUND
54 K11 18WT/DB FUEL INJECTOR NO.1 DRIVER
55 K52 20PK/BK EVAP PURGE SOLENOID CONTROL
56 - -
57 - -
58 - -
59 Z12 16BK/TN GROUND
60 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
61 F12 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
62 - -
63 - -
64 - -
65 C27 18DB/PK RADIATOR FAN RELAY CONTROL
66 K31 18BR FUEL PUMP RELAY CONTROL
67 K106 18WT/DG LEAK DETECTION PUMP SOLENOID CONTROL
68 L50 20WT/TN BRAKE LAMP SWITCH OUTPUT
69 K119 20LG/BK CLUTCH SWITCH
70 T141 20YL/RD CLUTCH INTERLOCK SWITCH SENSE
71 K29 20WT/PK BRAKE LAMP SWITCH SENSE
72 K21 20BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
73 D21 20PK SCI TRANSMIT
74 K80 20DG/LG PEDAL POSITION SENSOR NO. 1 SIGNAL
75 K6 18VT/WT 5V SUPPLY
76 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
77 K122 20DB/OR THROTTLE POSITION SENSOR NO. 2 SIGNAL
78 - -
79 G7 20WT/OR VEHICLE SPEED SENSOR SIGNAL
80 - -
81 K79 18OR/RD OXYGEN SENSOR 1/1 HEATER CONTROL
82 K12 18TN FUEL INJECTOR NO. 2 DRIVER
83 K13 18YL/WT FUEL INJECTOR NO. 3 DRIVER
84 K14 18LB/BR FUEL INJECTOR NO. 4 DRIVER
85 K199 18BR/VT OXYGEN SENSOR 1/2 HEATER CONTROL
86 - -
87 - -
88 A142 18DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
89 K20 18DG GENERATOR FIELD DRIVER (+)
90 Z12 16BK/TN GROUND
PL 8W-80 CONNECTOR PINOUTS 8Wa - 80 - 49
