User’s Manual
15
Power Button
Click on the Power button and the pull-down menu includes: <Lock>, <Exit>
and <Minimize>. Users can lock CMS system, exit CMS system, or minimize
CMS main window.
Display Mode
Click on any icon to view the connected camera images in multiple window
modes. The available viewing modes are 4-windows, 9-windows, 16-windows,
25-windows, 36-windows, 49-windows, 64-windows, 8-windows, 10-windows
and 13-windows. In addition, icons Sequence, Full screen, Last mode, Page
up and Page down give users variable options in monitor surveillance.
View Operator
Click on the <View Operator> icon and the pull-down menu are <Live all>,
<Re-sort>, <Snapshot>, <Video preview>, and <Sequence Setting>. Select
<Live all> to switch all sites to Live mode. <Re-sort> allows users to reset the
displaying layout to the listed orders in the site tree. Choose <Snapshot> to
save a snapshot of current window. <Video preview> is for preview and
selection of display mode. <Sequence Setting> is for setup of sequence order
list and sequence dwell time.
Emap
Click on the <Emap> icon to open up Emap program. Emap is a program that
allows users to illustrate positions of cameras on self selected images.
Record
Click on the <Record> icon and the pull-down menu includes: <Instant
record> and <Schedule record>. Users can initiate instant video record or
configure schedule record settings.
Playback
Click
on
the
<Pl
ayback>
icon
and
the
pull-
dow
n
m
enu
are
<Local
P
layba
ck>
and <Remote Playback>. Selecting <Local Playback> will bring up CMS
Player window, for users to playback video data stored in the local computer.
On the other hand, <Remote Playback> allows users to playback recorded
video stored in the HDD of the connected DVR. Please refer to Appendix A
for more information about CMS Player.
