EDAN F15 Series User Manual

F15 Series Fetal & Maternal Monitor User Manual Basic Operation
- 30 -
The battery is almost depleted and needs to recharge
immediately
No battery is loaded
Battery malfunction or battery charging stops due to its high
temperature
The battery is being charged.
3
Network connection
indicator and device
no.
the monitor is online, i.e. the monitor is connected to
internet;
the monitor is offline, i.e. the monitor is not connected to
internet or not well connected
4
Audio alarm indicator
the audible alarm is switched on; the current
audible alarm is switched off infinitely; the current audible
alarm is switched off temporarily. The silence duration is
configurable to 1min(default), 2min, 3min, or infinite. the
audible alarm reset is switched on (when the audible alarm is
configured to alarm reset.).
5
Recorder status
indicator
the recorder is in the process of printing, no printing is
going on
6
Print speed
The speed of the printing, eg., 3 represents 3 cm/min
7
Print remaining time
The remaining time of the printing
8
Monitoring timer
It indicates the duration of the current monitoring, and
zeroes when the START key is pressed.
9
Status indicator for
wireless transducer
(for F15 Air only)
The three icons from left to right indicate the status of the three
docking slots from inside to outside.
It indicates there’s no wireless transducer in the docking slot
It indicates the wireless transducer is being charged (when
the monitor is connected to the AC power supply)
It indicates the wireless transducer is fully charged
It indicates the wireless transducer is in the docking slot but
is not charged by the monitor (the monitor is not connected to the
AC power supply)
10
FTS-3 system
working channel
indicator
When FTS-3 is power on and connected to the monitor, the
indicator will be displayed, the number represents the
channel number.
11
FTS-3 Base Station
Battery indicator of
The battery power is low and needs to be charged. There is
alarm information on the screen.
The battery is almost depleted and needs to recharge
immediately
The battery is being charged.
