F15 Series Fetal & Maternal Monitor User Manual Alarms
- 61 -
TOCO Wireless Signal
Weak
The wireless signal of wireless
TOCO is too weak for the
system to analyze.
Check whether the ambulating mother
has reached the limit of the active signal
area-of-reach and whether the network
communication is fine.
DECG Wireless Signal
Weak
The wireless signal of wireless
DECG transducer is too weak
for the system to analyze.
Check whether the ambulating mother
has reached the limit of the active signal
area-of-reach and whether the network
communication is fine.
FECG Wireless Signal
Weak
The wireless signal of FECG
Fetal&Maternal Module is too
weak for the system to
analyze.
Check whether the ambulating mother
has reached the limit of the active signal
area-of-reach and whether the network
communication is fine.
Signals Overlap
(FHR1, FHR2)
US transducer 1 and US
transducer 2 are aimed at the
same fetal heart; the signals
overlap.
Adjust one of the US transducers until
another fetal heart signal is detected.
Signals Overlap
(FHR2, FHR3)
US transducer 2 and US
transducer 3 are aimed at the
same fetal heart; the signals
overlap.
Adjust one of the US transducers until
another fetal heart signal is detected.
Signals Overlap
(FHR1, FHR3)
US transducer 1 and US
transducer 3 are aimed at the
same fetal heart; the signals
overlap.
Adjust one of the US transducers until
another fetal heart signal is detected.
Signals Overlap
(FHR1, FHR2, FHR3)
US transducer 1, US
transducer 2 and US
transducer 3 are aimed at the
same fetal heart; the signals
overlap.
Adjust two of the US transducers until
the rest two fetal heart signals are
detected.
Signals Overlap
(DFHR, FHR2)
US transducer 2 is aimed at
the fetus that the spiral
electrode is attached to; the
signals overlap.
Adjust the US transducer until another
fetal heart signal is detected.
Signals Overlap
(DFHR, FHR3)
US transducer 3 is aimed at
the fetus that the spiral
electrode is attached to; the
signals overlap.
Adjust the US transducer until another
fetal heart signal is detected.
Signals Overlap
(DFHR, FHR2, FHR3)
US transducer 2 and 3 are
aimed at the fetus that the
spiral electrode is attached to;
the signals overlap.
Adjust the US transducers until the rest
two fetal heart signals are detected.
Probe MALF (FHR1)
US transducer 1 is
disconnected with the monitor
Connect US transducer 1 with the
monitor
Probe MALF (FHR2)
US transducer 2 is
disconnected with the monitor
Connect US transducer 2 with the
monitor
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
77／202
