F15 Series Fetal & Maternal Monitor User Manual Alarms
- 60 -
transducer.
Low Priority
Check Paper
There is no paper in the paper
drawer or the drawer is open.
Load paper and/ or close the drawer.
US1 UNPLUGGED or
US2 UNPLUGGED or
US3 UNPLUGGED
US transducer 1 or US
transducer 2 or US transducer
3 is not well connected.
Check the connection of the transducer.
US1 Signal Weak or
US2 Signal Weak or
US3 Signal Weak
FHR1 or FHR2 or FHR3 signal
is too weak for the system to
analyze.
Check if the US transducer is aimed at
the fetal heart; check if the alarm limits
are suitable; check the patient’s
condition.
FETUS 302 MODULE
MALF or Extend 302
MODULE MALF or
FETUS 417 MODULE
MALF
The fetus 302 module or
extend 302 module or fetus
407 cannot communicate with
the system successfully.
Restart the monitor and try again,
contact the manufacturer if the
connection still fails.
TOCO UNPLUGGED
TOCO transducer is not well
connected.
Check the connection of both TOCO
transducer and US transducer.
IUP LEADS OFF
DECG-IUP integrated cable is
not well connected.
Check the connection of the DECG-IUP
integrated cable.
DECG LEADS OFF
The spiral electrode or DECG
cable is not well connected.
Check the connection of the spiral
electrode or DECG cable.
DECG UNPLUGGED
The DECG Fetal&Maternal
Module is not well connected.
Check the connection of DECG
Fetal&Maternal Module.
FECG RLD Off
FECG electrodes (C1//N/F) are
not well connected.
Check the connection of the FECG
electrodes.
FECG LEADS
OFF(TOP/BOTTOM/C
4/F/R/N/L)
FECG leads
(top/bottom/C4/F/R/N/L) are
not well connected.
Check the connection of the FECG
leads (top/bottom).
DECG Signal Weak
DECG signal is too weak for
the system to analyze.
Check if the spiral electrode is well
attached to the fetus; check the patient’s
condition.
US1 Wireless Signal
Weak
Wireless FHR1 signal is too
weak for the system to
analyze.
Check whether the ambulating mother
has reached the limit of the active signal
area-of-reach and whether the network
communication is fine.
US2 Wireless Signal
Weak
Wireless FHR2 signal is too
weak for the system to
analyze.
Check whether the ambulating mother
has reached the limit of the active signal
area-of-reach and whether the network
communication is fine.
US3 Wireless Signal
Weak
Wireless FHR3 signal is too
weak for the system to
analyze.
Check whether the ambulating mother
has reached the limit of the active signal
area-of-reach and whether the network
communication is fine.
