F15 Series Fetal & Maternal Monitor User Manual Alarms
- 64 -
Low Priority
Signals Overlap
(FHR1, HR)
US transducer 1 has picked up
the maternal heart signal; the
signals overlap.
Reposition the US transducer 1 until the
fetal heart signal is detected.
Signals Overlap
(FHR2, HR)
US transducer 2 has picked up
the maternal heart signal; the
signals overlap.
Reposition the US transducer 2 until the
fetal heart signal is detected.
Signals Overlap
(FHR3, HR)
US transducer 3 has picked up
the maternal heart signal; the
signals overlap.
Reposition the US transducer 3 until the
fetal heart signal is detected.
Signals Overlap
(DFHR, HR)
The spiral electrode has picked up
the maternal heart signal; the
signals overlap.
Reposition the spiral electrode until the
DFHR signal is detected.
Signals Overlap
(FHR1, FHR2, HR)
US transducer 1 and US
transducer 2 have picked up the
maternal heart signal; the signals
overlap.
Reposition the US transducers until the
fetal heart signals are detected.
Signals Overlap
(FHR2, FHR3, HR)
US transducer 2 and US
transducer 3 have picked up the
maternal heart signal; the signals
overlap.
Reposition the US transducers until the
fetal heart signals are detected.
Signals Overlap
(FHR1, FHR3, HR)
US transducer 1 and US
transducer 3 have picked up the
maternal heart signal; the signals
overlap.
Reposition the US transducers until the
fetal heart signals are detected.
Signals Overlap
(DFHR, FHR2,
HR)
The spiral electrode and US
transducer 2 have picked up the
maternal heart signal; the signals
overlap.
Reposition the spiral electrode and US
transducer until the DFHR signal and fetal
heart signal are detected.
Signals Overlap
(DFHR, FHR3,
HR)
The spiral electrode and US
transducer 3 have picked up the
maternal heart signal; the signals
overlap.
Reposition the spiral electrode and US
transducer until the DFHR signal and fetal
heart signal are detected.
Signals Overlap
(FHR1, FHR2,
FHR3, HR)
US transducer 1, US transducer 2
and US transducer 3 have picked
up the maternal heart signal; the
signals overlap.
Reposition the US transducers until the
fetal heart signals are detected.
Signals Overlap
(DFHR, FHR2,
FHR3, HR)
The spiral electrode, US
transducer 2 and US transducer 3
have picked up the maternal heart
signal; the signals overlap.
Reposition the spiral electrode and US
transducers until the DFHR signal and
fetal heart signals are detected.
Signals Overlap
(eFHR, HR)
FECG Fetal&Maternal Module
has picked up the maternal heart
signal.
Relocate the electrodes until the fetal
heart signal is detected.
