A PPENDIX B | WDS Setup Examples
Basic WDS Link Between Two APs
– 243 –
CHECKING THE WDS LINK STATUS
When you have configured both access point VAPs, you can check the
status of the link from Access Point A.
Go to the Information>Station Status page. For the VAP 0 interface, the
Access Point B MAC address displays as a connected station.
Figure 65: WDS Example — Access Point A Station Status
