| Network Topologies
Infrastructure Wireless Bridge
– 35 –
Figure 9: Bridging Mode
WDS Links
Between Access Points
VAP 2
AP Mode
VAP 1
AP Mode
VAP 2
AP Mode
VAP 1
AP Mode
Network
Core
VAP 0
WDS-AP Mode
VAP 1
WDS-AP Mode
VAP 0
WDS-STA Mode
VAP 0
WDS-STA Mode
VAP 1
WDS-AP Mode
VAP 0
WDS-STA Mode
