C
HAPTER
1
| Introduction
Hardware Description
– 27 –
HARDWARE DESCRIPTION
Figure 1: Top Panel
Figure 2: Rear Panel
LED Indicators
Antennas
DC Power Socket
RJ-45 PoE Port
Reset Button
RJ-45 Console Port
