Chapter 11
| Interface Commands
Transceiver Threshold Configuration
– 413 –
Example
The following example sets alarm thresholds for the signal power received at port
25.
Console(config)interface ethernet 1/25
Console(config-if)#transceiver-threshold rx-power low-alarm -21
Console(config-if)#transceiver-threshold rx-power high-alarm -3
Console#
transceiver-threshold
temperature
This command sets thresholds for the transceiver temperature which can be used
to trigger an alarm or warning message.
Syntax
transceiver-threshold temperature {high-alarm | high-warning | low-alarm
| low-warning} threshold-value
high-alarm – Sets the high temperature threshold for an alarm message.
high-warning – Sets the high temperature threshold for a warning
message.
low-alarm – Sets the low temperature threshold for an alarm message.
low-warning – Sets the low temperature threshold for a warning message.
threshold-value – The threshold of the transceiver temperature.
(Range: -12800 - 12800 in units of 0.01 Celsius)
Default Setting
High Alarm: 75.00
°C
HIgh Warning: 70.00
°C
Low Alarm: -123.00
°C
Low Warning: 0.00
°C
Command Mode
Interface Configuration (ECS4120-28F SFP+ Ports 25-28
15
,
Other models: SFP/SFP+ Ports)
Command Usage
â—† Refer to the Command Usage section under the transceiver-threshold current
command for more information on configuring transceiver thresholds.
â—† Trap messages enabled by the transceiver-monitor command are sent to any
management station configured by the snmp-server host command.
15. Due to a chip limitation, transceiver data cannot be configured on ports 1-20 on the
ECS4120-28F. Default settings are used for these ports.
