Edge-Core ECS4120 Series

Chapter 21 | VLAN Commands
Configuring Protocol-based VLANs
– 587 –
3. Then map the protocol for each interface to the appropriate VLAN using the
protocol-vlan protocol-group command (Interface Configuration mode).
protocol-vlan
protocol-group
(Configuring Groups)
This command creates a protocol group, or to add specific protocols to a group. Use
the no form to remove a protocol group.
Syntax
protocol-vlan protocol-group group-id [{add | remove}
frame-type frame protocol-type protocol]
no protocol-vlan protocol-group group-id
group-id - Group identifier of this protocol group. (Range: 1-2147483647)
frame
23
- Frame type used by this protocol. (Options: ethernet, rfc_1042,
llc_other)
protocol - Protocol type. The only option for the llc_other frame type is
ipx_raw. The options for all other frames types include: arp, ip, ipv6, rarp.
Default Setting
No protocol groups are configured.
Command Mode
Global Configuration
Example
The following creates protocol group 1, and specifies Ethernet frames with IP and
ARP protocol types:
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type ip
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type arp
Console(config)#
23. SNAP frame types are not supported by this switch due to hardware limitations.
