Chapter 20
| ERPS Commands
– 552 –
This example displays statistics for all configured ERPS rings.
Console#show erps statistics
ERPS statistics for domain r&d :
Interface Local SF Local Clear SF
------------ ---------- --------------
(W) Eth 1/ 1 0 0
SF NR NR-RB FS MS
---------- ---------- ---------- ---------- ----------
Sent 0 62 948 0 0
Received 0 0 0 0 0
Ignored 0 0 0 0 0
EVENT HEALTH
---------- ----------
Sent 0 0
Received 0 0
Ignored 0 0
Interface Local SF Local Clear SF
------------ ---------- --------------
(E) Eth 1/ 3 0 0
SF NR NR-RB FS MS
---------- ---------- ---------- ---------- ----------
Sent 0 62 948 0 0
Received 0 0 0 0 0
Ignored 0 0 0 0 0
EVENT HEALTH
---------- ----------
Sent 0 0
Received 0 0
Ignored 0 0
R-APS with VC The R-APS Virtual Channel is the R-APS channel connection used to
tunnel R-APS messages between two interconnection nodes of a sub-
ring in another Ethernet ring or network.
R-APS Def MAC Indicates if the switch’s MAC address is used to identify the node in R-
APS messages.
Propagate TC Shows if the ring is configured to propagate topology change
notification messages.
Non-ERPS Device Protect Shows if the RPL owner node is configured to send non-standard
health-check packets when it enters protection state without any link
down event having been detected through SF messages
Holdoff The hold-off timer interval used to filter out intermittent link faults.
Guard The guard timer interval used to prevent ring nodes from receiving
outdated R-APS messages.
WTB The wait-to-block timer interval used to delay reversion after a Forced
Switch or Manual Switch has been cleared.
WTR The wait-to-restore timer interval used to verify that the ring has
stabilized before blocking the RPL after recovery from a signal failure.
WTB Expire The time before the wait-to-block timer expires.
WTR Expire The time before the wait-to-restore timer expires.
Table 103: show erps domain - detailed display description (Continued)
Field Description
