ELTEX ESR-3100 User Manual

ESR series service routers.ESR-Series. User manual
209
•
•
•
•
•
Step Description Command Keys
14 Specify a password for a user. esr(config-profile)# password
ascii-text <TEXT>
<TEXT> – string [8..32] ASCII
characters.
15 Create a destination address pool
(only for server).
esr(config)# address-
assignment pool <NAME>
<NAME> – destination addresses
pool name, set by the string of up
to 31 characters.
16 Set the subnet from which IP clients
will be issued (only for server).
esr(config-pool)# ip prefix
<ADDR/LEN>
<ADDR/LEN> – address and
prefix of the subnet.
17 Create an IKE gateway and switch to
its configuration mode.
esr(config)# security ike
gateway <NAME>
<NAME> – IKE protocol gateway
name, set by the string of up to
31 characters.
18 Bind IKE policy. esr(config-ike-gw)# ike-policy
<NAME>
<NAME> – IKE protocol policy
name, set by the string of up to
31 characters.
19 Set the mode of traffic redirection into
the tunnel.
esr(config-ike-gw)# mode
<MODE>
<MODE> – mode of traffic
redirection into the tunnel, takes
the following values:
policy-based — traffic is
redirected based on the
subnets specified in the
policies.
20 Specify the action for DPD (optional). esr(config-ike-gw)# dead-peer-
detection action <MODE>
<MODE> – DPD operation mode:
restart – connection
restarts;
clear – conection stops;
hold – connection holds;
none – the mechanism is
disabled, no action is
taken.
Default value: none
21 Specify the interval between sending
messages via DPD mechanism
(optional).
esr(config-ike-gw)#dead-peer-
detection interval <SEC>
<SEC> – interval between
sending messages via DPD
mechanism, takes values of
[1..180] seconds.
Default value: 2
