ESR series service routers.ESR-Series. User manual
•
•
Table 13 lists connectors, LEDs and controls located on the front panel of ESR-1700.
Table 13 – Description of ESR-1700 connectors, LEDs and front panel controls
№ Front panel
element
Description
1 HDD1 Connector for HDD installation.
2 HDD2 Connector for HDD installation.
3 USB1 Port for USB device connection.
4 USB2 Port for USB device connection.
5 Combo
Ports [1 .. 4]
4 ports of Gigabit Ethernet 10/100/1000BASE-X (SFP).
6 XG1 – XG8 Slots for 10G SFP+/1G SFP transceivers.
7 Status Current device status LED.
Alarm Alarm LED.
VPN VPN gateway operation mode LED (is not supported in the current version).
Flash Activity of exchange with data storage – SD card or USB Flash.
Power Device power LED.
Master Failover mode operation LED (is not supported in the current version).
Fan Fan operation LED.
RPS Redundant power supply LED.
8 F Functional key that reboots the device and resets it to factory default configuration:
Pressing the key for less than 10 seconds reboots the device;
Pressing the key for more than 10 seconds resets the terminal to factory settings.
9 Console Console port RS-232 for local management of the device.
10 OOB Ethernet port for router management.
