master(config)# interface gigabitethernet 1/0/1
master(config-if-gi)# vrrp id 1
master(config-if-gi)# vrrp ip 192.0.2.1/24
master(config-if-gi)# vrrp priority 20
master(config-if-gi)# vrrp group 1
master(config-if-gi)# vrrp preempt delay 60
master(config-if-gi)# vrrp
master(config-if-gi)# exit

master(config)# interface gigabitethernet 1/0/3
master(config-if-gi)# vrrp id 3
master(config-if-gi)# vrrp ip 198.51.100.1/24
master(config-if-gi)# vrrp priority 20
master(config-if-gi)# vrrp group 1
master(config-if-gi)# vrrp preempt delay 60
master(config-if-gi)# vrrp
master(config-if-gi)# exit
Configure firewall failover.
Select the unicast session reservation mode:
master(config)# ip firewall failover sync-type unicast
Select the IP addresses of the network interface from which messages will be sent when the Firewall is
running in session reservation mode:
master(config)# ip firewall failover source-address 203.0.113.1
Configure the neighbor's IP addresses when reserving Firewall sessions in unicast mode:
master(config)# ip firewall failover destination-address 203.0.113.2
Configure the UDP port number of the Firewall session reservation service:
master(config)# ip firewall failover port 3333
Enable Firewall session reservations:
master(config)# ip firewall failover
To configure security zone rules, create a profile for the firewall failover port:
master(config)# object-group service failover
master(config-object-group-service)# port-range 3333
master(config-object-group-service)# exit
To ensure that the VRRP processes states on a router are synchronized (master, backup), as well as
to synchronize their sessions using firewall failover, it is necessary to configure them to belong to
the same VRRP group.

