ESR series service routers.ESR-Series. User manual
Configure DHCP failover. For DHCP failover it is necessary to configure the following parameters: mode, local-
address, remote-address,VRRP routerbelonging to a group.
master(config)# ip dhcp-server pool LAN
master(config-dhcp-server)# network 192.0.2.0/24
master(config-dhcp-server)# address-range 192.0.2.10-192.0.2.20
master(config-dhcp-server)# exit
master(config)# ip dhcp-server
master(config)# ip dhcp-server failover
master(config-dhcp-server-failover)# mode active-standby
master(config-dhcp-server-failover)# local-address 203.0.113.1
master(config-dhcp-server-failover)# remote-address 203.0.113.2
master(config-dhcp-server-failover)# vrrp-group 1
master(config-dhcp-server-failover)# enable
master(config-dhcp-server-failover)# exit
To configure security zone rules, create a profile for the DHCP failover port:
master(config)# object-group service dhcp_failover
master(config-object-group-service)# port-range 873
master(config-object-group-service)# exit
Additionally, the following protocols must be allowed in the security zone-pair trusted self:
master(config)# security zone-pair trusted self
master(config-zone-pair)# rule 66
master(config-zone-pair-rule)# action permit
master(config-zone-pair-rule)# match protocol vrrp
master(config-zone-pair-rule)# enable
master(config-zone-pair-rule)# exit
master(config-zone-pair)# rule 67
master(config-zone-pair-rule)# action permit
master(config-zone-pair-rule)# match protocol tcp
master(config-zone-pair-rule)# match destination-port dhcp_failover
master(config-zone-pair-rule)# enable
master(config-zone-pair-rule)# exit
master(config-zone-pair)# rule 68
master(config-zone-pair-rule)# action permit
master(config-zone-pair-rule)# match protocol udp
master(config-zone-pair-rule)# enable
master(config-zone-pair-rule)# exit
View the status of VRRP processes using the following command:
master# show vrrp
Virtual router Virtual IP Priority Preemption State
-------------- --------------------------------- -------- ---------- ------
1 192.0.2.1/24 20 Enabled Master
3 198.51.100.1/24 20 Enabled Master
To start DHCP failover, first configure and enable the DHCP server that will be backed up.
DHCP failover uses TCP port 873 for synchronization, it must be enabled when configuring firewall.
