ESR series service routers.ESR-Series. User manual
598
•
•
Step Description Command Keys
2 Specify community for the
access via SNMPv2c.
esr(config)# snmp-server
community <COMMUNITY>
[ <TYPE> ]
[ { <IP-ADDR> | <IPV6-ADDR> } ]
[ client-list <OBJ-GROUP-
NETWORK-NAME> ]
[ <VERSION> ] [ view <VIEW-NAME> ]
[ vrf <VRF> ]
<COMMUNITY> – community for
the access via SNMP;
<TYPE> – access level:
ro – read-only access;
rw – read and write access.
<IP-ADDR> – IP address of the
client provided with the access,
defined as AAA.BBB.CCC.DDD
where each part takes values of
[0..255];
<IPV6-ADDR> – client IPv6
address, defined as X:X:X:X::X
where each part takes values in
hexadecimal format [0..FFFF];
<OBJ-GROUP-NETWORK-NAME> –
profile name of IP addresses, from
which snmp requests are
processing, set by the string of up
to 31 characters;
<VERSION> – the snmp version
supported by this community takes
the values v1 or v2c;
<VIEW-NAME> – SNMP view
profile name, set by the string of
up to 31 characters;
<VRF> – VRF instance name, set
by the string of up to 31
characters, for which access will
be granted.
3 Set the value of SNMP variable
that contains contact
information.
esr(config)# snmp-server contact
<CONTACT>
<CONTACT> – contact
information, sets by string with 255
characters length.
4 Set the DSCP code value for the
use in IP headers of SNMP
server egress packets (optional).
esr(config)# snmp-server dscp
<DSCP>
<DSCP> – DSCP code value, takes
values in the range of [0..63].
Default value: 63.
5 Enable router reboot by using
snmp messages (optional).
esr(config)# snmp-server system-
shutdown
6 Create SNMPv3 user. esr(config)# snmp-server user
<NAME>
<NAME> – user name, set by the
string of up to 31 characters.
