Disassembly and Assembly
3-34 EPSON Stylus Color 3000 Service Manual
Gear 29 (ASF Transmission Gear Set)
Paper Feed Gear
ASF Transmission Ratchet
Figure 3-32. ASF Gear Set Engagement
ASF Transmission Gear Set
Paper Feed Gear
E-ring
Bushing
PF Roller
Edge Guide
Bushing
Paper Feed
Shaft
Paper Feed
Rollers
Figure 3-33. Paper Feed Shaft Removal
