Epson Stylus Photo TX800FW

Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Revision C
DISASSEMBLY/ASSEMBLY
Overview
https://www.manualsbooks.com
96
Confidential
Table 4-2. Work Completion Check
Classification
Item
Check Point
Status
Scanner unit
Mechanism
Is glass surface dirty?  OK /  NG
Is any foreign substance mixed
in the CR movement area?
 OK /  NG
CR mechanism
Does CR operate smoothly?  OK
/  NG
Does CR operate together with
scanner unit?
 OK /  NG
Does CR make abnormal noise
during its operation?
 OK /  NG
LED
Does LED turn on normally?
And is white reflection test done
near home position?
 OK /  NG
ON-line Test
ON-line Test
Is the operation normal?  OK / 
NG
Copy
Copy
Is the local copy action normal?
OK /  NG
Adjustment
Specified
Adjustment
Are all the adjustment done
correctly
 OK /  NG
Lubrication
Specified
Lubrication
Are all the lubrication made at
the specified points?
 OK /  NG
Is the amount of lubrication
correct?
 OK /  NG
Function
ROM Version
Version:
 OK /  NG
Packing
Ink Cartridge
Are the ink cartridges installed
correctly?
 OK /  NG
Waste Ink pad
Are the waste ink pads adequate
to absorb?
 OK /  NG
Protective materials
Is the printer carriage placed at
the capping position?
 OK /  NG
Securing Printer ’ s
Carriage
Is the CR stopper placed at the
carriage securing position?
 OK /  NG
Others
Attachments,
Accessories
Have all the relevant items been
included in the package?
 OK /  NG
