Epson Stylus Photo TX800FW

Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Revision C
PRODUCT DESCRIPTION
Specification for Each Function
https://www.manualsbooks.com
45
Confidential
10
100
101
110
111
120
121
130
131
140
141
150
151
160
161
170
171
101
111
121
131
141
151
161
171
101
111
121
131
141
151
161
171
100
101
110
111
120
121
130
131
140
141
150
151
160
161
170
171
101
111
121
131
141
151
161
Cyan Yellow Light Black Magenta Light
Cyan Magenta
360dpi WF1 (MC2-1) LN2 dot
0.141mm (1/180inch)
32 dots
171
Table 1-42. Menu List for Setup Mode
Item
Function
Network Settings
Changes settings for Network.
• Confirm Network Settings
Displays the current settings. Status Sheet can be printed.
(Refer to Figure 1-11.)
• General Network Setup
Changes settings for printer name and TCP/IP (auto/
manual).
• Wireless LAN Setup
Enabling/disabling Wireless LAN.
• File Sharing Setup
Changes settings of the files in a memory card for file
sharing via network.
Home Network Print Settings
Makes the print settings via home networking using such as
a digital TV or PC.
Fax Setting
(Only Epson Artisan 800/Epson
Stylus Photo PX800FW/
TX800FW)
Changes settings for FAX. Refer to “ 1.7.5 FAX Function
(FAX Mode) ( p. 43 ) ” .
Bluetooth Settings
Changes settings for Bluetooth.
PictBridge Setup
The print settings and color correction to be used for the
camera direct print (PictBridge) can be selected and set.
When print conditions (paper type, paper size, layout,
quality, and auto correct) are specified from the DSC, the
DSC settings take priority over the settings made here. For
details, refer to “ 1.7.3 Camera Direct Print Function
(PictBridge) ( p. 39 ) ” .
Select Location
Selects a folder when printing from an external device other
than DSC.
Restore Default Settings
Restores the default settings for FAX and Network.
• Individual initialization of FAX or network settings is
available for Epson Artisan 800/Epson Stylus Photo
PX800FW/TX800FW.
• Individual initialization of network or other settings is
available for Epson Artisan 700/Epson Stylus Photo
PX700W/TX700W.
Note* : Only Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW.
Note : When the settings for the network are changed, network connection may be interrupted
temporarily.
Note : The numbers shown in the figure are nozzle numbers. The numbers and the color names
are not printed on an actual nozzle check pattern.
Figure 1-10. Nozzle Check Pattern
