2.1.4 PG setting
Following is the PG setting for Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W.
Figure 2-6. PG positions/Cam
PG
PG (+)
PG (Typ)
PG (-)
PG (++)
Type
Pos.1
→
Pos.2
→
Pos.3
→
Pos.4
PG (-)
PG (Typ)
PG (+)
PG (++)
PG measurement (mm)
1.2
1.7
2.35
5.8
Position name
Home position
Normal position
PG large position
PG max position
Description
Printing
EPSON brand paper
Plain paper printing
Avoiding friction of PG (-)
Envelope printing
Avoiding friction of PG (Typ)
CD/DVD
Not printing
 Capping
 Wiping
Ready position after
initialization
 AID
Capping
Capping
 Capping
 EJ release
Rotating direction for PF Motor
Clockwise
