Epson Stylus Photo TX800FW

Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Revision C
http://www.manuals4you.com
Confidential
Table 4-3. Procedure Differences
Parts name
Reference page
Artisan 800/PX800FW/TX800FW
Artisan 700/PX700W/TX700W
Housing is different.
The numbers of the screws and positions are partially different.
Upper Housing
Left Housing
Rear Left Housing
Upper Left Housing
Right Housing
 Artisan 800/PX800FW/TX800FW
◼ 4.2.2 " Removing the Housing " (p.102)
 Artisan 700/PX700W/TX700W
◼ 4.3.1 " Removing the Housing " (p.185)
Right Rear Housing
Main Board
The specification of the Main Board is different as well as the positions of the connectors.
 Artisan 800/PX800FW/TX800FW
◼ 4.2.3 " Removing the Circuit Board "
(p.115)
FAX
FAX
No FAX
 Artisan 700/PX700W/TX700W
◼ 4.3.2 " Removing the Circuit Board
(Artisan 700/PX700W/TX700W) " (p.194)
DISASSEMBLY/ASSEMBLY Overview 98
