Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Adjustment Using Adjustment Program
https://www.manualsbooks.com
Setting procedure
Figure 5-10. MAC Address Setting Screen
1.
Start the adjustment program.
2.
Select the “ Initial Setting” from the menu. The initial setting screen appears.
3.
Enter the last six digits of MAC address into the MAC address entry field, and
click the MAC Address input button.
(Enter the address again into the second entry field to confirm it.)
4.
Select
the
network
status
sheet
print
menu
on
the
printer
’
s
control
panel,
and
print
the sheet. Check the MAC address printed on the sheet to see if it is correct. refer
to Figure 1-11 "Sample of Network Status Sheet".
The MAC address required on the adjustment program is
written on the MAC address label on the Upper M/B Shield
Plate.
Make sure that the address written on the MAC address label
matches the MAC address settings in the EEPROM.
Figure 5-9. MAC Address Label
Do not use the MAC address of the label attached to the
Wireless LAN Board since the address is not used for this
the last six digits of MAC address
