Chapter 4
◼
4.2.1 Parts transferred from the old printer when replacing the Printer Mechanism (p101) has been added.
Made change in 4.2.2.1 ADF Unit (Artisan 800/PX800FW/TX800FW only) (p102).
Made change for reassembly in 4.2.2.2 Scanner Unit (p103).
Reassembly of 4.2.2.2 Scanner Unit (p103) has been added.
Caution of 4.2.3.2 Main Board / Grounding Plate M/B (p117) has been added.
Made change for caution in 4.2.4.1 Printhead (p124).
“ PF Encoder” has been deleted.
“ PF Scale” has been deleted.
Procedure and Checkpoint of 4.2.4.5 Ink Supply IC Holder Assy (p133) has been added.
Made change for reassembly in 4.2.4.6 Ink System (p135).
Procedure of 4.2.4.7 Lower ASF Paper Guide Assy (p138) has been added.
Made change in 4.2.4.8 CDR Tray Assy (p140).
Description has been added for reassembly in 4.2.4.11 Main Frame (p144).
Description has been added for reassembly in 4.2.4.13 EJ Frame Assy / EJ Release Frame Assy R/ EJ Release
Frame Assy L (p147).
Made change in 4.2.4.14 PF Motor (p150).
Description has been added for reassembly in 4.2.4.16 Carriage Unit (p154).
Caution of 4.2.4.18 Rear Frame (p159) has been added.
Description has been added for reassembly in 4.2.4.19 Upper Paper Guide L/R / PE Sensor (p161).
“ Paper Guide Front Assy” has been deleted.
Description has been added for reassembly in 4.2.4.20 Waste Ink Tray Assy (p163).
Procedure of 4.2.6.2 ADF Cover Assy/ADF Cover L (p175) has been added.
Made change for reassembly in 4.3.1.1 Scanner Unit (Artisan 700/PX700W/TX700W) (p185).
Caution of 4.3.2.2 Main Board/Grounding Plate M/B (Artisan 700/PX700W/TX700W) (p196) has been added.
