Epson Stylus Photo TX800FW

Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW/Epson Artisan 700/Epson Stylus Photo PX700W/TX700W
Revision C
TROUBLESHOOTING
FAX Troubleshooting (Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW only)
https://www.manualsbooks.com
85
Confidential
Table 3-34. Command/Response Code Table 3-34. Command/Response Code
Command/
response code
FCF value (HEX)
(LSB first: X=0)
Content
First
Second
PPS-MPS
BE
4E
Partial Page Signal-MultiPage Signal
PPS-EOP
BE
2E
Partial Page Signal-End Of Procedure
PPS-PRI-EOM
BE
9E
Partial Page Signal-Procedure Interrupt-
End Of Message
PPS-PRI-MPS
BE
5E
Partial Page Signal-Procedure Interrupt-
MultiPage Signal
PPS-PRI-EOP
BE
3E
Partial Page Signal-Procedure Interrupt-
End Of Procedure
PPS-EOS
BE
1E
Partial Page Signal-End Of Selection
PPS-NULL
BE
00
Partial Page Signal-partial page boundary
EOR-EOM
CE
8E
End Of Retransmission-End Of Message
EOR-MPS
CE
4E
End Of Retransmission-MultiPage Signal
EOR-EOP
CE
2E
End Of Retransmission-End Of Procedure
EOR-PRI-EOM
CE
9E
End Of Retransmission-Procedure
Interrupt-End Of Message
EOR-PRI-MPS
CE
5E
End Of Retransmission-Procedure
Interrupt-MultiPage Signal
EOR-PRI-EOP
CE
3E
End Of Retransmission-Procedure
Interrupt-End Of Procedure
EOR-EOS
CE
1E
End Of Retransmission-End Of Selection
EOR-NULL
CE
00
End Of Retransmission- partial page
boundary
RR
6E
-
Receive Ready
MCF
8C
-
Message ConFirmation
RTP
CC
-
ReTrain Positive
RTN
4C
-
ReTrain Negative
PIP
AC
-
Procedure Interrupt Positive
PIN
2C
-
Procedure Interrupt Negative
PPR
BC
-
Partial Page Request
RNR
EC
-
Receive Not Ready
ERR
1C
-
Response for End of Retransmission
Reserved (FDM)
FC
-
File Diagnostic Message
DCN
FA
-
DisCoNnect
CRP
1A
-
Command RePeat
Reserved (FNV)
CA
-
Field Not Valid
Command/
response code
FCF value (HEX)
(LSB first: X=0)
Content
First
Second
PIX
FF
-
PIXel image
Space
Other combinations
Unknown command/response
