405.1200.037.2 - Rel.: 2.21 of 25/02/2008
9-15
Preparation
for reception
The program VTWIN (see Software Manual) must be used for the transfer,
but the terminal must be set up to receive. This means carrying out the fol-
lowing steps:
• Check that the VT is off
• Check that there is a serial connection between the PC and the VT
• Switch on the VT with pressed down or with the VT on press
together + ; in either case wait a moment
VT terminal with no Modem function:
• The following mask appears.Press the function corresponding to the
port to be used. The VT is now ready to receive (refer to Software Man-
ual for transfer procedure)
VT terminal with Modem function:
• Proceed from the preceding mask; the following mask appears
• Choose the required transfer mode: MODEM if you intend to use a
modem or PC if you intend to use a serial port; press the corresponding
function
If the choose made is PC, the VT is ready to receive (see Software Manual
for transfer), if, on the other hand, you choose MODEM, the following
mask will appear
Enter
shift
Enter
Boot sequence forced
F1= ASP down/up load
F2= MSP down/up load
ENTER=run project
Boot sequence forced
F1= MODEM dn/up load
F2= PC dn/up load
ENTER=run project
