Video terminal VT130W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
5-6
Lines
●
Lists of bitmap images
●
Lists of texts
●
Local configuration of E-keys
●
Local configuration of F-keys
●
Macro field
Macros (Total/Commands x macro)
1024/16
●
Message field
●
Message help
256
●
Multilanguage texts
4 Langs.
●
Object - Indicator
Object - Potentiometer knob
Object - Selector knob
Object - Sliding potentiometer
Object - Sliding selector
Page
64
●
Page help
64
●
Password
10
●
Pipelines (Numero/Tot bytes)
Print
●
Print page (Total/Number of fields per page)
64/128
●
Programmable fonts
●
Project images
●
Public variables of ESANET network (Number/Tolat bytes)
Recipe field for recipe structure
Recipes (Number of variables per recipe)
128/256
●
Rectangles
●
Redefinable characters
Reports
32
●
Sequences - Random
128
●
Sequences - Start/stop
●
Static bitmaps
●
Symbolic field: Bit-group-structured dynamic bitmaps
1024*
●
Symbolic field: Single-bit-structured dynamic bitmaps
●
Symbolic field: Value-structured dynamic bitmaps
●
System messages
●
System variables assigned to recipe structure
●
Time long field
●
Time short field
●
Table 5.1: Functions and objects realizable with this VT (Part 3 of 4)
Code of terminal
VT130W
✳✳✳✳✳
Objects/Functions Quantity ▼
Unless otherwise stated, there is no limit to the number of includable elements, only the size of project memory sets a limit.
*) indicative value determined by the dimensions of the project, **) depends on memory available
