ECI Multi Functional Weighing Controller Operating Manual
Page 148
6) Total load cell capacity is entered. If there are more than
one load cells in the system, the total value of the
capacities of the load cells are entered. To proceed press
Key.
7) mV/V calibration is made according to the mV/V value of
the average load cell of the system. The information screen
indicating this is shown. Key is pressed to proceed.
